Duplex Service Drop ABC cable 600 V 2 cores

Home>ABC Cable>ICEA ABC Cable

Duplex Service Drop ABC cable  600 V  2 cores

Multiplex Overhead Secondary Distribution Cable

STANDARDS
National :  ICEA S-70-547
 DESCRIPTION

ZZHL Single Conductor Polyethylene-Covered Line Wire is rated for a 75°C normal conductor temperature, and is intended for use in overhead distribution circuits operating at primary or secondary voltages. The covering provides circuit protection against momentary contact with other conductors or trees. Because the covering carries no voltage rating, the conductors must be installed on insulators adequate for the intended service voltage. The user should consider the dielectric compatibility of the covering, insulator and conductor/insulator tie.

Conductor Construction
Conductors are available in the following constructions:
Aluminum conductor, steel reinforced (ACSR), concentric-lay stranded
Aluminum alloy 1350-H19 hard-drawn, concentric-lay stranded
Medium hard-drawn copper, solid or concentric-lay-stranded


Covering Material
The standard covering on the conductor is black linear low-density polyethylene (LLDPE).  Alternatively, a covering of black low-density crosslinked polyethylene (XLPE) with a 90°C temperature rating is available upon request.

The LLDPE and XLPE coverings meet the requirements of ANSI/ICEA S-70-547-2007 (Standard for Weather-Resistant Polyethylene Covered Conductors).

 Markings
The covering will bear the following surface markings:

ZZHL
Year and Plant of Manufacture
Conductor Size
Covering Material (LLDPE or XLPE)
 standard

ZZHL  Overhead Covered Line Wire is manufactured and tested in accordance with ANSI/ICEA S-70-547 (Standard for Weather Resistant Polyethylene Covered Conductors).
LINE WIRE - ACSR CONDUCTOR



Code Word

Phase Conductor

Neutral

Complete Cable

DC
Resistance
at 20°C
(ohm/kft)

Inductive
Reactance
(ohm/kft)

Ampacity*
(90°C)

Size
(# of wires)

Insulation
Thickness
(inch)

Size
(Stranding)

Overall
Diameter
(inch)

Cable
Weight
(lb/kft)

Shepherd/XLP

6 (7)

0.045

6 (6/1)

0.47

77

0.661

0.029

95

Retriever/XLP

6 (7)

0.060

6 (6/1)

0.50

85

0.661

0.031

95

Terrier/XLP

4 (7)

0.045

4 (6/1)

0.57

116

0.416

0.028

125

Yorkshire/XLP

4 (7)

0.060

4 (6/1)

0.60

125

0.416

0.029

125

Chow/XLP

2 (7)

0.045

2 (6/1)

0.70

177

0.261

0.027

165

Labrador/XLP

1 (19)

0.060

1 (6/1)

0.81

231

0.207

0.027

180

Bloodhound/XLP

1/0 (7)

0.060

1/0 (6/1)

0.89

285

0.164

0.028

220

Bull/XLP

1/0 (19)

0.060

1/0 (6/1)

0.89

285

0.164

0.026

220

For LLDPE insulation, remove "XLP" from code word.
Overall Diameter is the approximate circumscribed diameter of the assembly.
* Based on 40°C ambient temperature, crosswind at 2 ft/s, no sun.  For ampacity values at 75°C, contact our Sales Office.

DUPLEX SERVICE DROP AL 1350 NEUTRAL

Code Word

Phase Conductor

Neutral

Complete Cable

DC
Resistance
at 20°C
(ohm/kft)

Inductive
Reactance
(ohm/kft)

Ampacity*
(90°C)

Size
(# of wires)

Insulation
Thickness
(inch)

Size
(Stranding)

Overall
Diameter
(inch)

Cable
Weight
(lb/kft)

Collie/XLP

6 (7)

0.045

6 (7)

0.46

66

0.661

0.028

95

Cocker/XLP

6 (7)

0.060

6 (7)

0.49

74

0.661

0.030

95

Spaniel/XLP

4 (7)

0.045

4 (7)

0.55

98

0.416

0.027

125

Cairn/XLP

4 (7)

0.060

4 (7)

0.58

107

0.416

0.029

125

Doberman/XLP

2 (7)

0.045

2 (7)

0.68

148

0.261

0.027

165

Airedale/XLP

1 (19)

0.060

1 (7)

0.78

195

0.207

0.026

180

Basset/XLP

1/0 (7)

0.060

1/0 (7)

0.86

238

0.164

0.027

220

Malemute/XLP

1/0 (19)

0.060

1/0 (7)

0.86

239

0.164

0.026

220

For LLDPE insulation, remove "XLP" from code word.
Overall Diameter is the approximate circumscribed diameter of the assembly.
* Based on 40°C ambient temperature, crosswind at 2 ft/s, no sun.  For ampacity values at 75°C, contact our Sales Office.

DUPLEX SERVICE DROP AL 6201 NEUTRAL

Code Word

Phase Conductor

Neutral

Complete Cable

DC
Resistance
at 20°C
(ohm/kft)

Inductive
Reactance
(ohm/kft)

Ampacity*
(90°C)

Size
(# of wires)

Insulation
Thickness
(inch)

Size
(Stranding)

Overall
Diameter
(inch)

Cable
Weight
(lb/kft)

Viszla/XLP

6 (7)

0.045

6 (7)

0.47

66

0.661

0.029

95

Whippet/XLP

4 (7)

0.045

4 (7)

0.57

98

0.416

0.028

125

Schnauzer/XLP

2 (7)

0.045

2 (7)

0.70

148

0.261

0.027

165

Afghan/XLP

1/0 (7)

0.060

1/0 (7)

0.89

238

0.164

0.028

220

Heeler/XLP

1/0 (19)

0.060

1/0 (7)

0.89

239

0.164

0.026

220

For LLDPE insulation, remove "XLP" from code word.
Overall Diameter is the approximate circumscribed diameter of the assembly.
* Based on 40°C ambient temperature, crosswind at 2 ft/s, no sun.  For ampacity values at 75°C, contact our Sales Office.
Neutral sizes are diameter equivalent to ACSR.
