Triplex Service Drop ABC cable 600 V 3 cores
Multiplex Overhead Secondary Distribution Cable
STANDARDS
National : ICEA S-70-547
DESCRIPTION
ZZHL Single Conductor Polyethylene-Covered Line Wire is rated for a 75°C normal conductor temperature, and is intended for use in overhead distribution circuits operating at primary or secondary voltages. The covering provides circuit protection against momentary contact with other conductors or trees. Because the covering carries no voltage rating, the conductors must be installed on insulators adequate for the intended service voltage. The user should consider the dielectric compatibility of the covering, insulator and conductor/insulator tie.
Conductor Construction
Conductors are available in the following constructions:
Aluminum conductor, steel reinforced (ACSR), concentric-lay stranded
Aluminum alloy 1350-H19 hard-drawn, concentric-lay stranded
Medium hard-drawn copper, solid or concentric-lay-stranded
Covering Material
The standard covering on the conductor is black linear low-density polyethylene (LLDPE). Alternatively, a covering of black low-density crosslinked polyethylene (XLPE) with a 90°C temperature rating is available upon request.
The LLDPE and XLPE coverings meet the requirements of ANSI/ICEA S-70-547-2007 (Standard for Weather-Resistant Polyethylene Covered Conductors).
Markings
The covering will bear the following surface markings:
ZZHL
Year and Plant of Manufacture
Conductor Size
Covering Material (LLDPE or XLPE)
standard
ZZHL Overhead Covered Line Wire is manufactured and tested in accordance with ANSI/ICEA S-70-547 (Standard for Weather Resistant Polyethylene Covered Conductors).
LINE WIRE - ACSR CONDUCTOR.
|
Code Word |
Phase Conductor |
Neutral |
Complete Cable |
DC |
Inductive |
Ampacity* |
||
|
Size |
Insulation |
Size |
Overall |
Cable |
||||
|
Voluta/XLP |
6 (7) |
0.045 |
6 (6/1) |
0.54 |
119 |
0.661 |
0.033 |
95 |
|
Bolma/XLP |
6 (7) |
0.060 |
6 (6/1) |
0.58 |
134 |
0.661 |
0.035 |
95 |
|
Periwinkle/XLP |
4 (7) |
0.045 |
4 (6/1) |
0.64 |
175 |
0.416 |
0.031 |
125 |
|
Calma/XLP |
4 (7) |
0.060 |
4 (6/1) |
0.69 |
193 |
0.416 |
0.033 |
125 |
|
Cockle/XLP |
2 (7) |
0.045 |
4 (6/1) |
0.73 |
230 |
0.261 |
0.030 |
165 |
|
Conch/XLP |
2 (7) |
0.045 |
2 (6/1) |
0.78 |
264 |
0.261 |
0.030 |
165 |
|
Janthina/XLP |
1/0 (7) |
0.060 |
2 (6/1) |
0.93 |
370 |
0.164 |
0.030 |
220 |
|
Neritina/XLP |
1/0 (7) |
0.060 |
1/0 (6/1) |
0.99 |
424 |
0.164 |
0.030 |
220 |
|
Cenia/XLP |
1/0 (19) |
0.060 |
1/0 (6/1) |
1.00 |
425 |
0.164 |
0.029 |
220 |
|
Runcina/XLP |
2/0 (7) |
0.060 |
2/0 (6/1) |
1.09 |
522 |
0.130 |
0.029 |
265 |
|
Cerapus/XLP |
4/0 (19) |
0.060 |
2/0 (6/1) |
1.25 |
692 |
0.082 |
0.027 |
350 |
|
Zuzara/XLP |
4/0 (19) |
0.060 |
4/0 (6/1) |
1.34 |
799 |
0.082 |
0.027 |
350 |
|
For LLDPE insulation, remove "XLP" from code word. |
||||||||
|
Code Word |
Phase Conductor |
Neutral |
Complete Cable |
DC |
Inductive |
Ampacity* |
||
|
Size |
Insulation |
Size |
Overall |
Cable |
||||
|
Patella/XLP |
6 (7) |
0.045 |
6 (7) |
0.53 |
107 |
0.661 |
0.033 |
95 |
|
Albus/XLP |
6 (7) |
0.060 |
6 (7) |
0.57 |
123 |
0.661 |
0.035 |
95 |
|
Oyster/XLP |
4 (7) |
0.045 |
4 (7) |
0.63 |
157 |
0.416 |
0.031 |
125 |
|
Argo/XLP |
4 (7) |
0.060 |
4 (7) |
0.67 |
174 |
0.416 |
0.033 |
125 |
|
Clam/XLP |
2 (7) |
0.045 |
2 (7) |
0.76 |
234 |
0.261 |
0.030 |
165 |
|
Hyas/XLP |
1 (19) |
0.060 |
1 (7) |
0.89 |
311 |
0.207 |
0.029 |
180 |
|
Murex/XLP |
1/0 (7) |
0.060 |
1/0 (7) |
0.97 |
378 |
0.164 |
0.030 |
220 |
|
Purpura/XLP |
1/0 (19) |
0.060 |
1/0 (7) |
0.97 |
379 |
0.164 |
0.029 |
220 |
|
For LLDPE insulation, remove "XLP" from code word. |
||||||||
|
Code Word |
Phase Conductor |
Neutral |
Complete Cable |
DC |
Inductive |
Ampacity* |
||
|
Size |
Insulation |
Size |
Overall |
Cable |
||||
|
Hippa/XLP |
6 (7) |
0.045 |
6 (7) |
0.54 |
111 |
0.661 |
0.033 |
95 |
|
Barnacles/XLP |
4 (7) |
0.045 |
4 (7) |
0.64 |
163 |
0.416 |
0.031 |
125 |
|
Shrimp/XLP |
2 (7) |
0.045 |
2 (7) |
0.78 |
244 |
0.261 |
0.030 |
165 |
|
Gammarus/XLP |
1/0 (7) |
0.060 |
1/0 (7) |
0.99 |
394 |
0.164 |
0.030 |
220 |
|
Leda/XLP |
1/0 (19) |
0.060 |
1/0 (7) |
1.00 |
395 |
0.164 |
0.029 |
220 |
|
For LLDPE insulation, remove "XLP" from code word. |
||||||||
