BS Standard ABC Cable

Design.

1 Aluminium conductor with increased breaking load, round stranded compressed (RM)
2 Core insulation (XPLE black, UV-resistant, not flame retardant); 2 up to 4 cores of equal cross section are stranded together in left-hand lay, additionally 1 or 2 cores of reduced cross section can be co-stranded
Application

Can be used for fixed installation as overhead power lines up to 1.000 V incl.
Not suitable for direct burial.
This over-head cable provides reinforced insulation acc. IEC 61140 and fulfill therefore Class II acc. IEC 61140 It is not flame retardant. But this could be if requested change to a flame retardant cable

Specification

(1).  BS Standard ABC Cable

(2).  CCC,ISO9001,ISO14001, best quality control.

(3).  More than 20 years Proffessional experience, best service.

(4). We are a factory manufacturing ,Best production capability,best Price.

(5). 100% QC inspection before shippment.

Introduction

ABC Cable are overhead power lines using several insulated phase conductors bundled tightly together,

usually with a bare neutral conductor. They can improves safety and reliance of electrified wire netting.

Standard

1. B-230 Aluminum Wire, 1350-H19 for Electrical Purposes.

2. B-231 Aluminum Conductors, Concentric-Lay-Stranded.

3. B-232 Aluminum Conductors, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR).

4. B-399 Concentric-Lay_Stranded 6201-T81 Aluminum Alloy Conductors.

5. B498 Zinc-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR).

Applications:

TO supply 120 volt aerial service for temporary service at construction sites, outdoor or street lighting.

For service at 600 volt or lower at a conductor temperature of 75 maximum.
