1. Description for ACSR ZEBRA Conductor.
1. Aluminum Conductor steel reinforced.
2. Steel Reinforced.
3. Overhead Bare conductor.
4. 100mm2 acsr conductor.
2. Product Performance for ACSR ZEBRA Conductor.
1.The long-time working temperature of cable should not be higher than 250℃.
2.While installation the ambient temperature should not be lower than -20℃.
3.When core is in short circus (max 5s) the temperature should not exceed 250℃ Specifications
a.High tensile strength
b.Long life
c.Light in weight
d.Suitable for high as well as extra high overhead voltage lines
Standard: ASTM B232 ,IEC61089, BS215 part2, DIN48204, BS EN50182, GB/T 1179-2008.
