A,Specificationsa.High tensile strength
b.Long life
c.Light in weight
d.Suitable for high as well as extra high overhead voltage lines

B,Standard: ASTM B232 ,IEC61089, BS215 part2, DIN48204, BS EN50182, GB/T 1179-2008



C,Brief Description:

ACSR conductor consists of a solid or stranded steel core surrounded by strands of aluminium (E.C. GRADE).

ACSR Conductor may be manufactured for having a wide range of tensile strength as per requirement.

The principal advantage of these conductors are high tensile strength and light weight with longer spans as well as

with lesser supports. Due to the greater diameter of ACS Conductor a much higher corona limit can be obtained causing

big advantages on high as well as extra high voltage overhead lines.



D,Applications:

Used as bare overhead transmission cable and as primary and secondary distribution cable.

ACSR Conductor   offers optimal strength for line design. Variable steel core stranding enables

desired strength to be achieved without sacrificing ampacity. ACSR Conductor  are used extensively

 for overhead ground wires, river crossings etc. These ACSR Conductor  are available with us in various types for meeting the exact requirements of the clients.
